California Exclusive suspension lift - suggestions?

Discussion in 'T4 California Technical' started by tdi_ywg, Jan 10, 2018.

  1. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Greetings!

    Sitting in a campground in Sequoia National Park in California, USA at the moment. Lovely piece of the Earth to check out if you ever have the chance, but be sure to visit Canada before heading here as it's much more tranquil.

    After about 30K km in the past nine months, including 21K km on North American roads (for the uninitiated, it means inconsistent surfaces even when paved and, purely by choice, many gravel/dirt backcounty roads riddled with potholes large enough to double as duck ponds. I swear I drove through one the size of Hyde Park's Round Pond), I think I think I have decided where I want to go with the suspension on my 2001 Cali Exclusive: Up. I've no desire for a stiffer ride. I have not been disappointed by the feel of the original suspension.

    Here is what I am currently thinking:
    -change wheels/ti(y)res from 195/70/15 to 205/60/16 to gain about 10mm ride height
    -new rear springs to refresh rear ride height
    -tighten torsion bars to raise front end
    -install 75-100mm spacers

    Has anyone out there gone where I am thinking of going? Suggestions? I don't see any lift/spacer kits available in NA, which doesn't surprise me, so will likely have to import a kit from the EU or GB, or get the specs and have my machinist pal make me some spacers.

    Any suggestions for how much to tighten torsion bars?

    I think that's all for now.

    Thanks for the input!

    Scotty


  2. WelshGas
    Offline

    WelshGas Retired after 42 yrs and enjoying Life. Top Poster VIP Member

    10,137
    2,280
    244
    Location:
    Cowbridge
    Transmission:
    Auto
    Vehicle:
    T5 SE 180 4Motion
    Year:
    2014
    Hi. Loved both Sequoia and Yosemite National Parks.:thumb
    But back to your query. I’m not a suspension guru by any means, but if you don’t get the answers you need on this Forum I would suggest asking here.
    http://www.vwt4forum.co.uk/forumdisplay.php?f=146

    Raising suspension can be as problematic as lowering with changes in Drive shaft angles being moved to the extreme rather than mid-point with changes in wheel settings etc: and possible premature wear of drive shafts etc. If not done correctly.

    http://www.vwt4forum.co.uk/showthread.php?t=945529

    https://www.spaccer.com/en_AU/makes-and-models/vw/transporter-t4-bus.html

    https://www.seikel.de/shop/lift-kit-for-t4-front-wheel-drive/?lang=eh

  3. sidepod
    Offline

    sidepod Top Poster VIP Member

    2,974
    701
    121
    Vehicle:
    T4 PopTop
    Front end is easy, as you say just tighten the torsion bar nuts. These will need a 27mm socket , pref 3/4 drive and a BIG breaker bar. Soak them in WD40 for a couple of weeks before. Amount of movement is trial and error till you get it right. A good opportunity to dial out the Westy lean.

    Rear is easy. Just add extra doughnut spacers above the springs. 75-100 seems excessive?
    Again trial and error.

    It will alter camber angles but I don’t think you’ll be traveling quickly enough to be a problem.

    As WG says, the T4 forum has tons of stuff on the subject.

    Enjoy.

  4. pureinla
    Offline

    pureinla

    19
    3
    1
    Hey Scotty,
    T4 stuff is harder to come by in NA. The T4forum.de is a great resource I use all the time for my '99 Syncro. Check the Syncro forum for recommended heights. From memory I think you're shooting for 46-48 hub center to outermost rib on wheel arch. With 1cm less in front. Check to me sure. I'm looking at buying an Exclusive and will be doing the same thing.

    You can buy rear spring spacers from Cole Ford at Cave Van here...

    https://shop.cavevan.com/collections/eurovan/products/eurovan-lift-spacers

  5. pureinla
    Offline

    pureinla

    19
    3
    1
    I'm in British Columbia by the way. Where are you? I'd love to get inside an Exclusive before I buy one from Europe.

  6. mrcheesbrough
    Offline

    mrcheesbrough

    552
    38
    39
    Location:
    Wiltshire
    Transmission:
    Manual
    Vehicle:
    T4 PopTop
    Year:
    2001
    Use the rear springs and front torsion bars to gain height. If anything you should go for smaller wheels with a higher profile tyre to offer extra cushioning. Just take a look at any off-road vehicle and only the ones that prowl city streets have large diameter wheels with low profile tyres.

    • I Agree I Agree x 1
  7. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Thanks for the replies. I think I've revised my lift expectations down a bit. 50mm seems more reasonable. Perhaps some taller-sidewall 16" tires would be a good way to get some additional height? Not sure about that one.
    @pureinla, I live in Winnipeg but presently am in southern California. If you feel like coming to Winnipeg some time after April the van will be back there. You're more than welcome to check it out. Or, just pay for my wife and I to go across the pond and find one for you! I'm only half joking. Ok, less than half joking. Ask us. We'll happily go there again. :)

  8. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    @mrcheesbrough, I hear what you're saying but smooth ride on logging roads is not what I'm after. I need clearance plain and simple. Cushion does not matter when you are creeping down a logging road at 10km/h tops. I'm definitely not going low profile, though.
    Thanks for the input!


  9. pureinla
    Offline

    pureinla

    19
    3
    1
    Scotty,
    Thanks for the invite! Not sure I can wait that long. I've got bussiness in Stockholm next month. I've got a van in Germany I'd like to go see.
    Go for a lift. My '99 Syncro is lifted and I can cruise the logging roads here without a problem.

  10. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Stockholm eh? Pick up a T4 Syncro Doka 2.5 TDI for me while you're there. My cousins live in northern Sweden and I visited them this past summer. I could not believe how many Dokas there are there.
    If you want me and my wife to review anything about the one you're going to check out we'd be happy to.
    If you want to come down to Phoenix in a few weeks to check ours out we'll be there for about a week visiting relatives.

    Tell me about your wheels and tires please.

    Thanks,
    Scotty

  11. pureinla
    Offline

    pureinla

    19
    3
    1
    I was waiting in line for the ferry at Cortez island this summer and this was parked behind me...

    It was a Syncro. A little older short nose, probably a 2.4.

    My van runs on stock 15" steels with H&R spacers (25mm rear I think). Tires are BFG KO AT2 215 75 15's

    • I Like That! I Like That! x 1
  12. chuggertwo
    Offline

    chuggertwo

    93
    27
    18
    run mine on goldschmitt semi air suspension.
    much marcle leisure do dunlop kits.... and chap there is quite knowledgeable about such things.... I'm not!
    http://www.marcleleisure.co.uk/

  13. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Nice doka. There is one T4 doka in Winnipeg I know of and it's also a '92 or '93.
    How are you planning to ship your Cali to Canada, and to where?
    @chuggertwo: thanks for the link. I'll check that out.

  14. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    @chuggertwo: which Dunlop kit did you install? I do not see any kits for the T4.

  15. pureinla
    Offline

    pureinla

    19
    3
    1
    I'm going to container ship it to Vancouver I think. How did you get yours here? Shipping Roro to Tacoma was another option, but not that much cheaper as I'd still have to get to Tacoma.

  16. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Container shipped it to southern Ontario. My cousin in White Rock recently told me about someone in the YVR area who brings in multiple containers at a time from Europe. He thinks their pricing might be real good. If you want I can try to get contact info.

  17. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Alright, I think I have finalized my plans!

    Wheel/tires - 225/70/16 - 33.7mm increased height
    New HD springs - (701 511 105B) plus 38mm spacers
    Crank up torsion bars to match rear raise (and level things out left-to-right)
    Fox shock kit from GoWesty

    Methinks the pucker factor will be greatly reduced with the new setup.

  18. WelshGas
    Offline

    WelshGas Retired after 42 yrs and enjoying Life. Top Poster VIP Member

    10,137
    2,280
    244
    Location:
    Cowbridge
    Transmission:
    Auto
    Vehicle:
    T5 SE 180 4Motion
    Year:
    2014
    If the change in tyre size contributes 33.7 mm to the height rise then this will mean an increase in wheel/tyre diameter of 67.4 mm and a not insignificant effect on the Speedometer reading and an effect on the gearing and power output at the wheel.

    Is this going to be compensated for in some way?

  19. tdi_ywg
    Offline

    tdi_ywg

    13
    0
    1
    Location:
    Canada
    Transmission:
    Manual
    Vehicle:
    T4 Hightop
    Year:
    2001
    Not initially, but after I have a chance to evaluate things after the van is back on the road I'll decide if I want to upgrade my nozzles and have the ECU remapped.

  20. pureinla
    Offline

    pureinla

    19
    3
    1
    Hey Scotty, been a while for a few days. Yes, please let me know who's shipping containers.

    Skip the Fox. I have them, they barely have enough rebound damping for the Multivan. Definitely not enough for the CE
